Electric Striker with party mode fitted
Isolation switch
Having a party sick of releasing the gate every time someone whats to go out, then flick this switch probelm solved.
But remember to flick it back after the party.
arrow 003
electric striker
Download PDF file for FK680
circle001
Electric Gate Striker
Recess mounted with isolation switch in failsecure with 12VDC (400maA) wiring, Size 160mm height x 31mm wide
For Left Hand Locks

$85.00   P/N FK680
border box
Lockwood legge lock
Lockwood or Legge Locks
requires a FK660 Striker
FK670 striker and lock
Lockwood 001
requires a FK670 Striker
Above locks
requires a FK680 Striker
suitable locks for electric striker
line004
Electric Strikers that Suit certain locks
Most electric strikers requires a dry contact relay means a Dry contacts is 2 pieces of a precious metal touching or not touching. A wet contact is a blob of Mercury that wets each contact that makes the connection.

Electric Strikers work on the concept of Power To Release (PTR)

In this configuration, power (12 or 24V DC ) is  required for the striker will cause it to unlock. The striker will remain locked in a power failure.

Most Electric Strikers work mainly this way -
Download PDF file for FK660
Warranty - 12 months limited

$145    P/N FK660
Heavy duty electric striker
Heavy Duty Electric Striker
1 . Failsafe or Failsecure modes with internal switching.
2. 12V DC 230mA Voltage with continuosly rated solenoid.
3. Deep 12mm Recess to accept all types of Mortise locks &
Locksets - Keeper holding strength of 900 kgs
4. Satin Stainless Steel - Keeper & faceplate.
5. Screws, Fixing plates & fitting instructions kit supplied.
6. Suitable for Metal, Alauminium or Timber Frames.
7. Easy installation, compact and durable
8. Tested to over 500,000 opening cycles.
9. CE Approved
10. Reversible for Left or right hand use
Heavy Duty Electric Striker
1 . Failsafe or Failsecure modes with internal switching.
2. 12V DC 230mA Voltage with continuosly rated solenoid.
3. Deep 12mm Recess to accept all types of Mortise locks &
Locksets - Keeper holding strength of 900 kgs
4. Satin Stainless Steel - Keeper & faceplate.
5. Screws, Fixing plates & fitting instructions kit supplied.
6. Suitable for Metal, Alauminium or Timber Frames.
7. Easy installation, compact and durable
8. Tested to over 500,000 opening cycles.
9. CE Approved
10. Reversible for Left or right hand use
Heavy Duty Electric Striker
1 . Failsafe or Failsecure modes with internal switching.
2. 12V DC 230mA Voltage with continuosly rated solenoid.
3. Deep 12mm Recess to accept all types of Mortise locks &
Locksets - Keeper holding strength of 900 kgs
4. Satin Stainless Steel - Keeper & faceplate.
5. Screws, Fixing plates & fitting instructions kit supplied.
6. Suitable for Metal, Alauminium or Timber Frames.
7. Easy installation, compact and durable
8. Tested to over 500,000 opening cycles.
9. CE Approved
10. Reversible for Left or right hand use
Striker in a gate
electric striker with a striker plate attached
Striker mounted in a post
Electric Gate Striker
Recess mounted with extended faceplates in failsafe or failsecure with 12VDC (400maA)  wiring, Size 250mm height x 31mm wide

$68.50   P/N FK685
external electric striker
001 with striker
Electric Gate Striker
External Mounted
Reversible for Left or right hand use

$89.50   P/N FK664
CE Approved
C-Tick Certified
TVU Approved
5 Year Warranty
FEATURES:
Surface mount type, face mount for easy installation
Ideal for Gates and Doors where rim locks are used
Low current 33Ù COIL as standard, 12v DC, 350mA
Ideal for, Access Control and Intercoms applications
Strong durable construction, Satin Chrome
Quality product built to ISO9227 standards
ECONOMICALY priced
5 Year Manufacturers Warranty
SPECIFICATIONS:
Type: Surface face mount design
Operational voltage: 12v DC, or 12-16v AC
Current draw: 360mA
Coil type: 30Ù coil
Operation features: Standard momentary operation
Colour: Satin Chrome Plated
Dimensions: H 146mm x W 36mm x D 25mm
Warranty: 5 Years Manufactures Warranty
CHROME SURFACE MOUNT ELECTRIC DOOR STRIKE / LATCH
Optional surface mount electric door latch

Function: On activation of the strike release the door (power to open) The strike will unlock when power is applied and will remain unlocked until the power is removed.
electric striker 02
Electric Gate Striker
Recess mounted with extended faceplates in failsafe or failsecure with 12VDC (400maA)  wiring, Size 250mm height x 31mm wide
For Right Hand Locks

$85.00   P/N FK690
  Related Products
Gate
Locks
Range of Gate Locks
Gate
Hinges
Range of gate Hinges
steel post
Steel
Post
End
Caps
End caps
lock diagram
Bits & Pieces
of a Lock

Electric Strikers for Gates and Doors

NC = unlocked if no electrical voltage
NO = locked if NO electrical voltage
