620 Rapid Automatic barrier for beams up to 4 m
Brand - FAAC

240V rapid hydraulic boom gate for beams up to 4m.
Electro-hydraulic operator with lock in opening and closing
Release system with triangular key
Patented electronic slow-down device
5.5 second opening time, 70 cycles per hour.

$2943.57

Popper is the first electromecanical barrier on the market to use an ergonomic design! It has a mechanical and electrical limit switch, as well as an emergency release system. Maximum boom length is 4m.

CE POPPER
MAIN POWER SUPPLY 230 V 50 Hz
MOTOR'S POWER SUPPLY 230 V 50 Hz
OPERATING TEMPERATURE -25° C to +70° C
MAXIMUM BOOM LENGTH 400 cm
RATED POWER 200 W
ABSORBED POWER 1,0 A
CAPACITOR 10 uf
CYCLES PER HOUR 40 %
OPENING TIME 8 sec IP 54
LUBRICATION Permanent greasing
MAX BOOM WEIGHT 5,0 KG / 4 MT
WEIGHT 35 kg

Solar Power Boom Gate Model GPCA5000

Power 12V DC solar Panel
Temp -25 + 70C
Current Max 1.5Amp
Max Boom 6 Metres
Weight 6 Kgs
Duty Cycle 100%
Receiver Top secuirty rolling code
Torque 200N
Power 1Kw
Pinion Z18
IP 44
Optional GSM access controller to open the gate by mobile phone

Smart Computerized System
Digital and Computerized control panel with built-in invertors for slowing down the boom gate at the end of travel for smooth and long lasting operation

Digital Control Panel with zero current consumption on stand-by
State of the art control panel with Digital Technology. The only one to have ZERO current consumption including a beam sensor to prevent discharge of batteries and save solar energy to allow more operations per day.

Two operating programs
You can select one out of two most popular operation programs to operate the boom gate.
1.Step by step
You close it and open it when you want via a remote or GSM.
2. Automatic operation
Open and close on set timing in seconds/mins

Built-in Solar panel regulator
98% efficiency solar regulator to maximize solar energy consumption

Electro Mechanic limit switches

Over-Ride Keys

Made in Australia

Any length of Boom upto 6 Metres

100% Duty cycle for Heavy Duty operation

Robust Gear Box & Powerful 12V DC Motor

Can handle up to 6 Mtr Boom Arm

Specifications

Control Equipment and Devices Integration

A wide range of devices can be connected to control the boom gate operations.

- Loop in the ground mainly use for vehicular exiting
- Hand held Remote
- GSM System using your Mobile phone
- Key Switch Box
- Card Reader
- Photo Safety Cell
- Keypad
- Ticketing Machine
- Push Button from a Watch house or Counter

Installation is very easy: you just need 4 dynabolts and a power source! Wires used to operate the boom gate can be inserted into concrete by using a concrete saw.
