Large strap hinge heavy duty
Large strap hinge for timber
Strap Hinges For Gates
Long Strap Hinges For Gates
Gate Strap Hinges are mainly used on wooden gates providing more support and a larger surface over the timber because timber is soft.
Strap hinges are normally quite long and help to reinforce the wooden structure of the gate to which they are fixed. For especially heavy Gates,

Strap hinges come in a variety of styles, including wrought iron strap hinges and gate strap hinges


Large Strap Hinges
Large H/duty plate hinges gates up to 800 kgs
Strap Hinge 350x75 25mm pin with screws

$76.00 pair   P/N   HN640 - Left Side

$76.00 pair   P/N   HN641 - Right Side

Coach Bolts
Coach Bolts or coach screws
Attaching strap hinges to timber gates use Coach Bolts or coach screws
Tip  - LEFT or RIGHT ? - You must standing where ever you can actual see the hinge is it on your left or right? .
These strap hinges has a flap big enough to bolt straight on to brick in some cases it's your only option.
Strap hinges
Strap Hinges
Strap Hinge 300x65mm 19mm pin
For gates up to 400 kgs

$54.00 pair   P/N  HN613-  Left Side

$54.00 pair   P/N  HN614 - Right Side
Strap Hinges for Timber gates
 Long custom strap hinges
Strap Hinges for Timber Gates
Strap Hinge 300x50mm 14mm pin
For gates up to 100 kgs

$22.50 pair   P/N  HN610-  Left Side

$22.50 pair   P/N  HN611 - Right Side

$40.00 both sides Left and right pairs
                                    P/N HN618

Strap Hinges For Timber Gates

10.70mm
dia
arrow103
dia symbol
arrow106
Pin
25.5mm
arrow104
  75mm
arrow102
70mm
arrow100
  430mm
arrow105
150mm
arrow101
We can Powder Coat
Your Strap hinge to
any colour
send me an email

gary@gatesplus.com.au

heavy duty strap hinges black
arrow2000
arrow1000
arrow3000
arrow400
arrow1300
  350mm
Left Hinge Short Strap1
Left Hinge Short Strap2
Right Hinge Short Strap2
Right Hinge Short Strap1
ar001
  200mm
ar003
50mm
ar004
  145mm
ar002
  85mm
Left Hinge Short Strap- Pair - $15.50
Part Number - HN602
Screw On / Screw On  - Zinc plated
Pin size 14mm
Gates up to 120 kgs
Right Hinge Short Strap - Pair - $15.50
Part Number - HN604
Screw On / Screw On  - Zinc plated
Pin size 14mm
Gates up to 120 kgs
ar007
55mm
ar006
36mm
Suggestion.
If you are using a soft timber for a gate it might be a good idea to place another strap on the other side of the hinge placing the timber between the 2 straps just like a sandwich.
200mm
200mm
  350mm
  75mm
dia symbol
Pin
25.5mm
Plate
200x200mm x 10mm
4 x holes 12mm
These Strap hinges are designed to carry heavy timber gates comes with 2 plates one each side of the gate, The mounting plate is also designed to spread the load over 4 bricks the plate is 10mm thick, the hinge is out from the mounting plate to allow the gate to swing out to 120 degrees in an open position. Can be powder coated to all colorbond colours. These Strap Hinges are made from Steel then Zinc plated then powder Coated.  Life span - 22 years
Left Side Strap Hinge
1 Pair - $180.00
Part Number - HN626

Pair is Top and Bottom hinge one side

Pin size 25mm
Gates up to 800 kgs
Right Side Strap Hinge
1 Pair - $180.00
Part Number - HN624

Pair is Top and Bottom hinge one side

Pin size 25mm
Gates up to 800 kgs
Remember - To order the correct side hinges you need to stand where you can see them and only then   they will be on your right or left.
Right and left Side Strap Hinge -
2 Pairs both sides - $320.00
Part Number - HN628


Pin size 25mm
Gates up to 800 kgs
10.70mm
dia symbol
arrow1470
Weight - 6 kgs
adjustable timber strap hinge
Adjustable Timber Strap Hinge - upto 250 kgs Timber Gates

Part Number - HN630
Strap Hinges - Adjustable
Locinox Stainless Steel Strap Hinges
Vandal proof 4D strap hinge for wooden gates
locinox strap hinge
300mm long
includes hinge and strap

HN650  $195 /pair
400mm long
includes hinge and strap

HN652  $215 /pair
Max Gate weight 150 kgs

each hole 9mm Holes

Design to Swing a Gate -180 Deg

PLUS they are adjustable

arrow2000
arrow1000
40mm
   500mm long
arrow1007
500mm long
includes hinge and strap

HN654  $235 /pair
140 mm
Vandal Proof

Locinox Stainless Steel Strap Hinges



A very Smart Looking strap hinge from Locinox unlike any other strap hinge it offers vandal proof protection a first. The stainless steel hinge can be adjusted in 4  dimensions. Height, depth, left / right alignment and rotational direction can be adjusted. Adjustments can be made after installing the hinges. This way your gate is always perfectly aligned even if the timber bends and twist due to weather conditions during the life of the Gate.
NEW FEATURE - Vandal Proof
Made from 304 Stainless
